Specifications: General Family Merit Series Line Voltage 120 (Volts) Number of Outlets 9 Number of Isolated Banks 0 Outlet Descriptions All 9 outlets regulated and conditioned -eight on the rear panel and one on the front Rack Mountable Yes Rack Ears Included Yes Front Panel Meter(s) Eight element, Bi-color bar graph meter to indicate input line voltage Front Media Light(s) No Control Front panel: – On/Off switch Voltage Regulation Regulation capture range 97 VAC to 141 VAC Output Voltage: 120 VAC ±5V Compliances CSA us USB Charging N/A Low Voltage Trigger N/A AC Power Cord 10 ft. captive AC power cord with NEMA 5-15 Plug Dimensions 19″ W x 11″ D x 1.75″ H Weight 15.75 lbs AC Protection AC Protection Technology Voltage Regulation Extreme Voltage Shutdown Extreme Current Shutdown Under-Voltage Shut off 75V Over-Voltage Shut off 145 VAC Maximum Current Rating 15 (Amps) Initial Clamping Level 400 volts peak at 500 A Filtration Filtration Technology Standard Level RFI/EMI Filtration Filtration Rating-16dB @ 10KHz -33dB @ 100 kHz -48dB @ 400KHz Signal Line Protection No Other Specifications Spike Protection Modes: Line to Neutral Energy Dissipation: 225 joules Peak Impulse Current: 15,000 amps Construction: Steel Chassis, Black Painted Master Pack Qty 2
